0.375 Inch Thick by 24 Inch Width by 24 Inch Length G10 Glass Sheets Reinforced Epoxy
(Micarta) (High Pressure Laminates)
G10 Glass Reinforced Epoxy - natural
(yellowish to light green) Technical Data Sheet
Chemical Resistance Chart
The most versatile all-around laminate and
composite, this grade is a continuous glass woven fabric base impregnated
with an epoxy resin binder. It has extremely high mechanical strength, good
dielectric loss properties, and good electric strength properties, both wet and
dry.
NEMA G-10 MIL-I-24768/2 GEE, IPC
4101/20, IEC 60893-3 Type 2 EP GC 201
Grade NEMA FR-4 certs to MIL-I-24768/27 GEE-F, IPC 4101/21, IEC 60893-3 Type 2
EP GC 202
0.375 Inch Thick by 24 Inch Width by 24 Inch Length G10 FR4 Plates and Sheets | |||||
Thickness (in.) | Width (in.) | Length (in.) | Part # | Price | Order Online |
---|---|---|---|---|---|
0.375 ±.030" | 24 | 24 | KS-2991 | $171.95 | Add to Order |
Rev. 04-23, 05-22, 12-21, 11-21 |
