0.625 Inch Thick by 12 Inch Width by 48 Inch Length G10 Glass Sheets Reinforced Epoxy

5/8" Thick G10FR4 Sheets

(Micarta) (High Pressure Laminates) G10 Glass Reinforced Epoxy - natural (yellowish to light green) Technical Data Sheet    Chemical Resistance Chart
The most versatile all-around laminate and composite, this grade is a continuous glass woven fabric base impregnated with an epoxy resin binder. It has extremely high mechanical strength, good dielectric loss properties, and good electric strength properties, both wet and dry.



NEMA G-10 MIL-I-24768/2 GEE, IPC 4101/20, IEC 60893-3 Type 2 EP GC 201
Grade NEMA FR-4 certs to MIL-I-24768/27 GEE-F, IPC 4101/21, IEC 60893-3 Type 2 EP GC 202

0.625 Inch Thick by 12 Inch Width by 48 Inch Length G10 FR4 Plates and Sheets
Thickness (in.) Width (in.) Length (in.) Part # Price Order Online
0.625 ±.040" 12 48 KS-3004F $654.24 Add to Order
Rev. 10-23, 04-23, 10-22, 05-22
