7.156 Inch OD x 7.031 Inch ID G10 Tubes Glass Reinforced Epoxy - .062" Wall

(Micarta) (High Pressure Laminates) G10 Glass Reinforced Epoxy - natural (yellowish to light green) Technical Data Sheet    Chemical Resistance Chart
The most versatile all-around laminate and composite, this grade is a continuous glass woven fabric base impregnated with an epoxy resin binder. It has extremely high mechanical strength, good dielectric loss properties, and good electric strength properties, both wet and dry.

NEMA G-10 MIL-I-24768/2 GEE, IPC 4101/20, IEC 60893-3 Type 2 EP GC 201
Grade NEMA FR-4 certs to MIL-I-24768/27 GEE-F, IPC 4101/21, IEC 60893-3 Type 2 EP GC 202

Tubes are manufactured in random lengths between 30" and 36".
The pricing and minimums are based on the 36".

Tubes can also be produced in 42" to 48" random lengths for the same price.
Measured lengths of 36"±1" and 48"±1" are also available - call for pricing.

7.156 Inch OD x 7.031 Inch ID G10 FR4 Tubes with a .062" (1/16) Wall Thickness
**Minimum's Apply, Non Stocked Item. 36" Random Lengths, 48" are available on request.
Part # Outside Diameter (in.) Inside Diameter (in.) Price Per Foot Order Online Minimum Order (ft.)
KM-5971 7.156 7.031 $125.88 Add to Order 6 Ft
Rev. 08-22, 06-22, 02-22, 11-21
Phenolic Tube Tolerances
↓ Inside Diameter ↓
Outside Diameter Turned OD
Tolerance
Steel
Mandrel
Built-up
Mandrel
0.125"  to  0.749" ±.005" ±.003" -
0.750"  to  1.999" ±.005" ±.004" -
2.000"  to  4.000" ±.008" ±.006" -
4.001"  -  12.000" ±.025" ** ±.010" -
12.001" - 18.000" ±.030" ** ±.030" ±.060"
18.001" - 24.000" ±.035" ** ±.040" ±.075"
24.001" - 48.000" ±.040" ** ±.060" ±.090"

** Tubes over 8.000" OD are supplied as wound, which
are always fractions of an inch larger than stated OD.

** Tubes turned to the following OD tolerance
can be quoted on request.
